EM232 4 outputs ×12bits

Model

EM232 4 outputs ×12bits

Product  Description

4AO;Resolution:16bits; 12 bits resolution voltage output;

11 bits resolution current output

Input Feature

From bus current consumption

22mA

From L+ current consumption

92mA

Power loss

2.5W

Number of analog Input

 -

Signal input type

 -

Maximum input voltage

 -

Maximum input current

 -

Voltange input range: Unipolar

 -

Voltange input range: Bipolar

 -

current input range

 -

Resolution

 -

Bipolar,full-scale range

 -

Unipolar, full-scale range

 -

Analog to digital conversion time

 -

Output Feature

Number of analog Input

4

Input voltage range

-10~+10V

Input current range

0~20mA

Load inpedance

·for voltage outputs

Min:5KΩ

·for current outputs

Max:0.5KΩ

Resolution

12 bits voltage output;

11 bits current output

Data word format

·Displayable:voltage output

-32，000~+32，000

·Displayable:current output

0~32，000

Basic error

±0.5% of full range

Dimensions(W x H x D)(mm)

71.2×80×62

Order Number

UN 232-OHD22-0XA0
