PLC / 200 Series
EM231 8AI x 14 bits
Артикул: UN 231-0HH32-0XA0
аналог Siemens S7-200 — SIMATIC S7-200
- Аналоговый модуль ввода 200-ой серии. VW region
- 8 аналоговых входов
- разрешение: 14 bits
- Сильная и устойчивая защита от помех
Model | EM231 8 inputs × 14 bits |
Product Description | 8AI,24V DC; Resolution:14bits; High immunity,stable |
Technical Specification | |
From bus current consumption | 20mA |
From L+ current consumption | 60mA |
Power loss | 2W |
Number of analog Inputs | 8 |
Input type | Differential |
Voltange input range: Unipolar | 0~5v,0~10V |
Voltange input range: Bipolar | ±2.5V,±10V |
input range:current | 0~20mA,+ 20mA |
Resolution | 14bit |
Bipolar,full-scale range | -32,000 to +32,000 |
Unipolar, full-scale range | 0 to +32,000 |
Cable Length (unShielded) | 300m |
Input impedance | ≥10M Ω Voltage Input |
250 Ω Current Input | |
Isolation tested for contact (field to logic) | No |
Analog to digital conversion time | <250µs |
Common-mode rejection | 40db,DC to 60Hz |
Common-mode voltage | Signal voltage + Common-mode voltage≤12V |
Maximum input voltage | 30V DC |
Maximum input current | 32mA |
Dimensions(W x H x D)(mm) | 71.2×80×62 |
Order Number | UN 231-OHF22-0XA0 |
