PLC / 200 Series
EM222 16 outputs Relay
Артикул: UN 222-1HH22-0XA0
аналог Siemens S7-200 — SIMATIC S7-200
9,941 ₽
- Цифровой модуль вывода 200-ой серии
- 16 цифровых выходов, 24V DC/25V AC
- Релейный выход
- Релейная защита, сильная и устойчивая защита от помех
Model | EM222 16 outputs Relay |
Product Description | 16DO,24V DC/250V AC Relay; high immunity |
The bus current consumption | 98mA |
Power loss | 3W |
Number of digital outputs | 16 |
Signal output type· | Relay |
Isolation | Relay |
Rated voltage | 24V DC or 250V AC |
Permissible voltagerange | 5~30V DC,20~250V AC |
Rated current | 2A |
Lamp load | 30W DC/200W AC |
Cable Length(Shielded) | 500m |
Cable Length(unshielded) | 150m |
Switching frequency | 1Hz |
Lifetime contact mechanical | 10,000,000 |
Lifetime contactmechanical( rated load voltage) | 100,000 |
Dimensions(W x H x D)(mm) | 71.2×80×62 |
Order Number | UN 222-1HH22-0XA0 |
